A revolutionary new way to experience flight. Utilizing the power of rockets. Shedding the burden of a tail, because why not? Hand crafted by the greatest minds ever gathered in Stillwater.

pHoeNix

Fast. Powerful. Exhilarating.

Orange
BuzzDouble
    Description
  • - Sleek flying wing design.
  • - Can be deployed by one person.
  • - Designed to reach over 300 mph.
  • - Over 50 possible rocket configurations.
  • - Made with state of the art composite manufacturing.
  • - Build to fly in 3 days.
  • - Flexible space for personalized components.
  • Isometric View
    Specifications
  • - Aircraft Type: Flying Wing
  • - Propulsion: Electronic Motor (Puller)
  • - Wingspan: 33 in
  • - Length: 12.5 in
  • - Weight: 2.01 lbs
  • - Wing Area: 1.1 ft^2
  • Top View
    Components
  • - Motor: 1950kv BadAss
  • - Motor Style: Outrunner
  • - ESC: Falcon Elite 65A
  • - Servos: KST X08H Plus (included)
  • - Main Battery: MaxAmps 1050mAh 5s LiPo
  • - Receiver: Jeti RX-7 Assist
  • - Rocket: Up to F-Class

  • *All components can be customized/swapped out.
  • Internals View
    Launch Rail
  • Our Simple, yet Unique, Launch Rail Provides:
  • - Easy Deployment for the Pilot.
  • - Up to 60 degrees of launch angle.

  • Our Aerodynamic, Top-Mounted Rail Guide Allows for Simple Mounting to any standard T-slot 8020 launch rails.
  • Launch Rail

Quality Built

Phoenix is a true composite remote control aircraft. It utilizes a blend of carbon fiber, fiberglass, Kevlar, and balsa wood to maximize the structural integrity and stiffness of the aircraft without compromising weight. The skin composition was optimized through multiple iterations to ensure minimal damage in worst case loading situations. The total aircraft weight before electronics is ~0.75 pounds.

Rocket Assisted Take-Off

With any 8020 launch rail, Phoenix can reach upwards of 150 mph on a rocket-assisted take-off. Utilizing the complementary launch rail, it can also be sabot launched by the pilot with one simple pull.

Sophisticated Design

Flying wings are typically harder to fly than other conventionally styled rc planes. Phoenix was meticulously designed to fly faster than any other plane at the rc field. Its specially designed, thin, reflexed airfoil minimizes drag, and increases aerobatic performance at speed. The swept endplates increase aerodynamic control while also increasing the effective aspect ratio of the aircraft.

Cutting-Edge Technology

The competiton build of Phoenix is equipped with an optimal avionics setup for high speed applications. Weilding a Falcon Elite ESC with built-in telemetry, coupled with a BadAss 1950kv motor. It also employs the power of a 5s 1050mAh LiPo battery, but can be configured with a range of different batteries. *Any components can be customized as desired.

Testimonials

"If you want to go fast, buy a phoenix" -anonymous
